Drilling series
HY5225A
Drilling capacity: 25mm
Motor power: 750/900W
Class of Speed: 12
Share This Product:
  • Specifications
Mini machine drill press made in china with standard attachment HY5225A

Quick Detail:
Drilling capacity: 25mm
Motor power: 750/900W
Class of Speed: 12
Spindle taper: MT3

Description:
HY5225A Mini machine drill press belongs to one of our most Mini machine drill press. It is new condition not used Mini machine drill press. And it is medium in size and delicate in design. This medium size machine drill press is made in China, but have the similar quality with German drill press. The main features are as below:

1. Adjustable depth stop
2. Quiet belt drive operation
3. FWD/REV toggle switch
4. Headstock runs in precision-bearings
5. Speeds allow selection of optimum speeds at the work piece
6. Cast iron plastic handle, easy to operate
7. Humanized design, electromagnetic switch is available.
8. High precision.

Specifications:
ModelHY5225A
Drilling capacityØ25mm(1")
Motor power750/900W
Chuck Capacity5-20mm
Spindle stroke85mm
Class Of Speed12
Speed 50/60Hz280~2380/340~2860 R.P.M
Spindle taperMT3
Auto-feeding step of worktable180mm
Max.distance from spindle end to surface of table685mm
Max.distance from spindle end to surface of base1175mm
Swing360mm
Table size290X290mm
Base Size460X270mm
Column DiameterØ72mm
Height1600mm
N.W./G.W.71/75kg
Packing size1140X500X300mm
Number Picture

Chuck guard

Front  switch

Keyless drill chuck

Key type drill chuck

Vice

Laser
